AXIS#.SAFEPARAM.SDB.FUNCTIONACTIVATION
Description
Indicates whether Safe Dynamic Brake (SDB) is ready for activation.
|
Value |
Description |
|---|---|
|
0 |
Never active |
|
1 |
Ready for activation |
Context
For complete SDB information refer to SDB (Safe Dynamic Brake).
Related safety parameters:
- AXIS#.SAFEPARAM.SDB.DELAYBEFOREDIAGNOSE
- AXIS#.SAFEPARAM.SDB.DELAYBEFORESWITCHING
- AXIS#.SAFEPARAM.SDB.READBACKSOURCE
Versions
|
Action |
Version |
Notes |
|---|---|---|
|
Implemented |
02-00-00-000 |
Implemented in SMM revision v0.54 |
General Information
|
Type |
Read/Write |
|
Units |
N/A |
|
Range |
0, 1 |
|
Default Value |
0 (Never active) |
|
Data Type |
Integer |
|
Stored in Non -Volatile Memory |
No |
Industrial Ethernet Information
|
Command |
Index |
SubIndex |
Data Type |
Units |
Float Scale |
Access |
PDO Mappable |
|---|---|---|---|---|---|---|---|
|
AXIS1.SAFEPARAM.SDB.FUNCTIONACTIVATION |
3158h |
01h |
Unsigned8 |
- |
- |
Read/Write |
No |
|
AXIS2.SAFEPARAM.SDB.FUNCTIONACTIVATION |
3258h |
01h |
Unsigned8 |
- |
- |
Read/Write |
No |
